R-FR
Mechanical seal R-FR
Temperature: -20°~180°
Pressure: ≤1.4 MPa
Speed: ≤15 m/sec
R-FR is a mechanical seal used in Fristam pumps. Typically, Fristam pumps use a face tandem: one on the product side (L) and the other on the drive side ®. All wetted materials are FDA certified Face consolidation for the pump Fristam to the centrifugal pump FP, FPE, FPX, FPR, FPH, FPHP, FZX Face consolidation for the pump Fristam to the rotary piston pump FKL, FL, FLF, FLFN Face consolidation for the pump Fristam to the rotary pump FLII, FL II PD Face consolidation for the Fristam pump to the multistage pump FM Face consolidation for the Fristam pump to the mixer and mixer FS, FSI, FSH
| d1 (H6) | d2 | d3 | d7 (H8) | l1 | l2 | L +-0.5 | |
| R-FR-22L | 22 | 18 | 36 | 41,2 | 20 | 7,5 | 27.5 |
| R-FR-22R | 22 | - | 36 | 41,2 | 20 | 7,5 | 27.5 |
| R-FR-30L | 30 | 22 | 44 | 48 | 22 | 7.6 | 29.6 |
| R-FR-30R | 30 | - | 44 | 48 | 22 | 7.6 | 29.6 |
| R-FR-35L | 35 | 28 | 49 | 55.5 | 26 | 8.6 | 34.6 |
| R-FR-35R | 35 | - | 49 | 55.5 | 26 | 8.6 | 34.6 |
Sort by:
17468_22__L__SIC/SIC__EPDM__304
Seal mechanical pump FRISTAM R-FR 22, L, SIC/SIC, EPDM, 304
17468_35__L__SIC/SIC__EPDM__304
Seal mechanical pump FRISTAM R-FR 35, L, SIC/SIC, EPDM, 304
17468_35__R__CAR/SS__EPDM__304
Seal mechanical pump FRISTAM R-FR 35, R, CAR/SS, EPDM, 304
17468_22__R__CAR/SS__EPDM__304
Seal mechanical pump FRISTAM R-FR 22, R, CAR/SS, EPDM, 304
17468_30__L__SIC/SIC__EPDM__304
Seal mechanical pump FRISTAM R-FR 30, L, SIC/SIC, EPDM, 304
17468_30__R__CAR/SS__EPDM__304
Seal mechanical pump FRISTAM R-FR 30, R, CAR/SS, EPDM, 304
